Seaco L6 Modular Aluminum Marina Dock System

Seaco L6, Modular Aluminum Dock System delivers flexibility in fully adjustable slips to change, expand, and scale a marina’s layout.

Versatile design – Bolt on Slide in

With its modular framing and fastening system, Seaco’s Commercial Marina Dock System saves labor costs as floats are simply through bolted on to the sub-frame cross bracing. Likewise, decking panels can be quickly slid into the deck support of the chassis’s aluminum extrusion.

Lasting value

The combination of marine grade extruded aluminum framing and drop in place aluminum “Seaco Nut” fastening system make for a corrosion free installation. Built to last, Seaco’s Commercial Marina Dock System, greatly reduces maintenance and service costs.

Solid engineering

Seaco’s engineered bolted assemblies make for consistent frame squareness throughout all modular frame sizes. Standard dock frame sizes are available in 4, 6, 8, 10 and 12 foot widths or any length you want. No-Flex Hinges lock for a continuous rigid dock structure.

Good for the environment

Treated wood products are no longer a good choice for marina construction and are difficult to depose of responsibly. Aluminum is easily repaired and, at the end of its service cycle, can be recycled with less harm to the environment.

Build what you need, when you need it.

Whether its our drawings or yours Seaco’s design and construction services can provide leadership to help steer a project’s completion.

SEAFLEX Anchoring SystemSeaco marina installations use the exclusive SEAFLEX mooring system, suitable for both fresh and salt water.

Advantages:

Elongates, stretches and retracts to hold the dock secure and stable in all weather conditions.

Dampens the forces hitting the dock, increasing the life of the structure.

Seaco Marine L6 The Forks Port, Winnipeg, Manitoba, Canada
Main Docks
Length
– 16’
– 20’
– 24’
– 26’
Widths
6’, 8’, 10’, 12’
6’, 8’, 10’, 12’
6’, 8’, 10’, 12’
6’, 8’, 10’, 12
Gangways
Length
– 16’
– 20’
– 24’
– 26’
– 30’
– 40’
Widths
4’, 5’
4’, 5’
4’, 5’
4’, 5’
4’, 5’
4’, 5’
Ramps
Length
– 4’
– 8’
– 16’
– 20’
– 24′
Widths
4’, 5’
4’, 5’
4’, 5’
4’, 5’
4’, 5’

Finger Docks
Length
– 16’
– 20’
– 24’
– 26’
– 30’
– 40’
Widths
4’, 6’
4’, 6’
4’, 6’
4’, 6’
4’, 6’
4’, 6’
Floats
77 Different Sizes and Buoyancy Ratings
BROCHURE
Seaflex Anchoring System
Ace Float logo
IMANNA Laboratory logo
Lab Tested
